| Brand Name : | REINFORCE |
| Model Number : | REINFORCE-70 |
| Certification : | ISO9001 |
| Price : | USD 1.7-3/ square meter |
| Payment Terms : | T/T |
| Supply Ability : | 2000 Square meters per week |
| Delivery Time : | 14-30works day |
Underground Pipeline Protection Mesh
Galvanized Wire Pipeline Reinforced Mesh Description:
Pipeline reinforced mesh (also known as concrete weight coating mesh) is a specially welded steel mesh designed for reinforcing concrete coatings on offshore, subsea, underground and marine pipelines. Its corrugated structure provides excellent bonding with concrete, effectively preventing cracking, improving structural integrity and extending the service life of pipeline systems.
Galvanized Wire Pipeline Reinforced Mesh Specification:
| Product Name | Galvanized Wire CWC Pipeline Reinforced Mesh |
| Material | low carbon galvanized wire |
| Wire diameter | 2.0mm/2.2mm/2.4mm/2.7mm etc. |
| Hole size | 25.4mm x 67mm |
| Hardness Range | 485N/mm2~650N/mm2 |
| Exposed Wire Edge | ≤ 2.5 mm |
| Technique | point welded |
Galvanized Wire Pipeline Reinforced Mesh Export different kinds can choose:
| Ref Number | Main Wire (mm) | Cross Wires (mm) | Roll Width Dimensions (mm) | Roll Length Dimensions (mm) |
| CWC20 | 2.0@25.4 | 2.0@67 | 190.5 | 140/280 |
| CWC22 | 2.2@25.4 | 2.2@67 | 190.5 | 140/280 |
| CWC24 | 2.4@25.4 | 2.4@67 | 190.5 | 140/280 |
| CWC27 | 2.7@25.4 | 2.7@67 | 190.5 | 140/280 |
Galvanized Wire Pipeline Reinforced Mesh Good Features:
• High tensile strength, firm welding, not easy to break or deform
• Deep crimped design for superior concrete adhesion
• Good flexibility, easy to wrap around pipes during construction
• Hot-dip galvanized surface for strong corrosion resistance
• Stable performance under harsh marine and underground environments
• Uniform mesh opening, consistent quality, easy to install
Galvanized Wire Pipeline Reinforced Mesh Application:
• Offshore oil and gas pipelines
• Subsea and underwater pipelines
• Underground water supply / drainage pipelines
• Concrete weight coating reinforcement
• Coastal and marine engineering pipeline protection
Our Company Profile:
Our company has 6 sets of the world's most advanced complete wire mesh welding production lines, with an annual production capacity of more than 5 million square meters, and is equipped with a complete set of testing equipment such as tensile testing machines, bending testing machines, and galvanized testing ensure that the products meet domestic and international relevant quality and standard requirements.
Our company has passed the ISO 9001 quality management system, ISO 14001 environmental management system and ISO 45001 occupational health and safety management system three international standard certifications, indicating that the company's comprehensive management capabilities in the fields of quality, environment and occupational health and safety have reached international standards.
|
|
